ZWCAD Professional Edition 2026 v26 | Software for 2D/3D Design for PC Windows
Product Details ＋
Although it comes packed with many dedicated parameters, it boasts a clean layout that gives users the possibility to create a new drawing from scratch and use a step-by-step approach which comes in handy, especially for rookies as they are offered assistance throughout the entire process, or choose one of the template files.
The application enables you to select between imperial or metric units, zoom in or out of the working environment, specify angle values, set up drawing limits, use polar tracking mode for restricting the mouse cursor to specified angles, work with line types and layers, and assign colors to objects.
Moreover, you can extract or calculate geometric information from objects (area and circumference calculation), divide objects (lines, arcs, circles) into several equal segments, and specify the 2D and 3D coordinate values.
Features of ZWCAD Professional
- Open or save DWG/DXF drawings from ACAD.
- Import DGN files and exchange drawings with MicroStation.
- Add annotation with voice record
- Trigger commands by mouse gesture
- Multi-filter for selection, select objects that match specific properties
- Convert text information as a barcode or QR code and embed it in the drawing
- Multi-line text, full-text editing functions
- Insert raster images, support formats like JPEG, PNG, and BMP
- Collect geometry together into one object, which you can use repeatedly
- Check and debug codes for correct lisp programs
- Compare two similar drawings and highlight the differences
- Perform calculations within CAD just as you would with a desktop calculator
- Create and modify 3D models with solid, surface, and mesh modeling tools
- Assign how things print, such as color, line weight, line type, etc
- Output DWG drawings to other formats for sharing
Technical Details and System Requirements
- Supported OS: Windows 11 / Windows 10 / Windows 8.1 / Windows 7 x64
- Processor: Multi-core Intel Series or above, Xeon or AMD equivalent
- RAM: 4GB (8GB or more recommended)
- Free Hard Disk Space: 4 GB or more recommended
System Requirements ＋
• Processor: 1 GHz or faster with 2 or more cores
• RAM: 4 GB
• Storage: 64 GB or larger
• System firmware: UEFI, Secure Boot capable
• TPM: Trusted Platform Module (TPM) version 2.0
Activation Instructions ＋
1. Go to Settings > System > Activation.
2. Click 'Change product key'.
3. Enter the 25-digit code received in your email.
4. Follow instructions to finish activation.
